Full HD USB Camera with Galaxycore GC2093 Sensor
- PCB Dimensions: 38 mm × 38 mm
- Lens Mount: M12 × 0.5
- Lens Distortion: ≤ 1.0 %
- Field of View: DFOV 86°, HFOV 77°, VFOV 49°
Description
Reviews
Product Overview
The CM_USB2_11 is a robust Full HD USB camera module featuring the high-performance Galaxycore GC2093 sensor, specifically engineered for demanding industrial and commercial applications. This reliable imaging solution delivers precise 1080p video quality with consistent performance, making it ideal for access control systems, biometric verification, and automated industrial processes where accuracy and reliability are critical.
Equipped with an advanced SONIX ISP and balanced wide-angle optics, the CM_USB2_11 ensures optimal image processing and comprehensive scene coverage. The module's industrial-grade construction and stable operation make it suitable for continuous use in challenging environments, from factory floors to secure access points.
Key Features
- Full HD 1080p resolution with Galaxycore GC2093 sensor for reliable imaging
- Integrated SONIX ISP ensures advanced image processing capabilities
- Wide 86° diagonal field of view provides comprehensive scene coverage
- Microphone support enables synchronized audio-video capture
- Industrial-grade construction for reliable operation in demanding environments
- M12×0.5 industrial lens mount for secure optical assembly
- Optimized for access control and biometric applications
- USB-UVC compliance ensures broad platform compatibility
Technical Specifications
Sensor Information
Resolution Performance
Optical Characteristics
Physical Properties
Detailed Specifications
| Parameter | Specification | Notes |
|---|---|---|
| Sensor Brand | Galaxycore | Leading manufacturer of high-performance imaging sensors |
| Sensor Model | GC2093 | Advanced Full HD sensor with integrated processing |
| Sensor Size | 1/2.9" | Optimized for high-quality imaging in compact form |
| Sensor Pixel Size | 2.8 µm × 2.8 µm | Large pixels for enhanced sensitivity and dynamic range |
| Sensor Resolution | 1920 × 1080 | Full HD resolution for detailed image capture |
| Shutter Type | Rolling | Electronic rolling shutter |
| ISP Support | Yes | SONIX Image Signal Processor integrated |
| Microphone Support | Yes | Audio capture capability for synchronized AV applications |
| Auto Focus | No | Fixed focus lens system for consistent performance |
| Lens Type | Normal | Wide-angle lens for comprehensive coverage |
| Field of View | DFOV 86°, HFOV 77°, VFOV 49° | Balanced wide-angle coverage for access control applications |
| Lens Mount | M12 × 0.5 | Industrial-standard lens mount for reliability |
| Distortion | ≤ 1.0 % | Minimal distortion for accurate biometric recognition |
| PCB Size | 38 × 38 mm | Standard industrial form factor |
| Connection Type | USB-UVC | Universal Video Class compliant |
| Codec Support | YUY2 / MJPEG | Dual codec support for flexible implementation |
Applications
The CM_USB2_11 camera module is engineered for security, access control, and industrial automation applications where reliability, consistent performance, and accurate imaging are essential. Its robust design and advanced features make it suitable for demanding environments.
Access Control
Secure entry systems requiring reliable facial recognition and visitor identification. The consistent imaging quality ensures accurate authentication in various lighting conditions for office buildings, secure facilities, and residential complexes.
Biometric Terminals
Advanced biometric verification systems combining facial recognition with other authentication methods. The high-quality imaging supports precise biometric matching for time attendance, secure access, and identity verification applications.
Kiosks
Self-service terminals and interactive kiosks requiring reliable video capture for user interaction, age verification, and transaction security. The robust construction ensures continuous operation in public environments.
Factory Automation
Industrial vision systems for quality control, component verification, and automated inspection processes. The reliable performance ensures accurate imaging in manufacturing environments with varying lighting conditions.
Time & Attendance
Employee time tracking systems utilizing facial recognition for accurate attendance recording. The consistent performance ensures reliable operation in corporate and industrial settings.
Security Systems
Integrated security solutions requiring reliable video capture for monitoring and verification. The microphone support enables audio recording for comprehensive security documentation.
Ordering Information
SKU: CM_USB2_11
Vendor: Camemake Technologies
Lead Time: Typically 3-4 weeks for standard orders
Minimum Order: 1 unit (evaluation kits available)
Customization: Lens options, filter additions, and industrial housing designs available for volume orders
Support: Comprehensive technical documentation, SDK access, and engineering support for security system integration
Package Contents
Note: Industrial mounting brackets, extended temperature range options, and custom cable assemblies are available separately. Please consult our industrial solutions catalog for accessories designed for demanding environments.
Technical Support
Camemake provides extensive technical support for the CM_USB2_11 industrial camera module, including detailed integration guides, API documentation, and sample applications specifically tailored for access control and biometric systems. Our engineering team offers specialized consultation for security system integration and industrial automation projects.
For system integrators and developers, we provide a comprehensive SDK supporting Windows, Linux, and embedded platforms, with specialized libraries for facial recognition integration and industrial vision applications. Documentation includes detailed performance metrics, environmental testing results, and implementation guidelines for reliable operation in demanding conditions.
